ZOTAC GAMING GeForce RTX 3050 6GB GDDR6 LP Graphics Card
The ZOTAC GAMING GeForce RTX 3050 6GB GDDR6 LP is a compact low-profile graphics card designed for small-form-factor PCs, office system upgrades, multimedia systems, and Full HD gaming builds where space and power requirements are important.
Powered by NVIDIA Ampere architecture, the card features 2304 CUDA cores, 6GB of GDDR6 memory, a 96-bit memory interface, and a boost clock of up to 1470MHz.
Key Features
- NVIDIA GeForce RTX 3050 6GB
- NVIDIA Ampere Architecture
- 2304 CUDA Cores
- 6GB GDDR6 Memory
- 96-Bit Memory Interface
- 14Gbps Memory Speed
- 1470MHz Boost Clock
- PCI Express 4.0 x8
- Low-Profile Design
- Dual-Slot Form Factor
- PCIe Bus Powered
- No External GPU Power Connector Required
- 70W Maximum Power Consumption
- HDMI 2.1
- DisplayPort 1.4a
- NVIDIA DLSS
- NVIDIA G-SYNC
- DirectX 12 Ultimate
- Low-Profile Bracket Included
- Box Version
Compact Low-Profile Design
The ZOTAC RTX 3050 LP is designed specifically for systems where a standard full-height graphics card may not fit.
With dimensions of approximately 161 × 70.6 × 36 mm, the card uses a compact dual-slot, low-profile design that makes it suitable for many slim desktop and small-form-factor systems. ZOTAC states that the design fits in up to 99% of PC builds.
6GB GDDR6 Memory
The card features 6GB of GDDR6 graphics memory operating at 14Gbps through a 96-bit memory interface.
This provides a modern graphics memory configuration for Full HD gaming, multimedia, GPU acceleration, and everyday graphics workloads.
NVIDIA Ampere Architecture
The GeForce RTX 3050 6GB is based on NVIDIA Ampere architecture and supports technologies including:
- Ray Tracing
- NVIDIA DLSS
- NVIDIA G-SYNC
- Game Ready Drivers
- NVIDIA Studio Drivers
- DirectX 12 Ultimate
PCIe Bus Powered
One of the biggest advantages of this model is its low power requirement.
The card has a 70W maximum power consumption and draws its required power directly through the PCI Express slot, meaning no additional 6-pin or 8-pin PCIe power cable is required.
Display Connectivity
The Low Profile model provides:
- 1 × DisplayPort 1.4a
- 1 × HDMI 2.1
- Up to 2 Simultaneous Displays
HDMI 2.1 supports features including 4K 120Hz HDR, 8K 60Hz HDR, and Variable Refresh Rate where supported by the connected hardware and display.
Power Requirements
Maximum GPU Power: 70W
Recommended Power Supply: 450W
External Power Connector: None
Power Source: PCI Express Slot
Box Contents
According to ZOTAC, the retail box includes:
- ZOTAC GAMING GeForce RTX 3050 6GB GDDR6 LP
- User Manual
- Low-Profile Bracket
That last point is important because this is specifically the Box Version.
Specifications
Brand: ZOTAC
Series: ZOTAC GAMING
Model: GeForce RTX 3050 6GB GDDR6 LP
Official SKU: ZT-A30510L-10L
GPU: NVIDIA GeForce RTX 3050 6GB
Architecture: NVIDIA Ampere
CUDA Cores: 2304
Video Memory: 6GB GDDR6
Memory Speed: 14Gbps
Memory Interface: 96-bit
Boost Clock: 1470MHz
Interface: PCI Express 4.0 x8
DisplayPort: 1 × DisplayPort 1.4a
HDMI: 1 × HDMI 2.1
Maximum Displays: 2
HDCP: 2.3
DirectX: 12 Ultimate
OpenGL: 4.6
Cooling: Fan + Heatsink
Slot Size: Dual Slot
Form Factor: Low Profile
Power Consumption: 70W
External Power Connector: None
Recommended PSU: 450W
Dimensions: 161 × 70.6 × 36 mm
Package Type: Box
The ZOTAC GAMING GeForce RTX 3050 6GB GDDR6 LP Box Version combines modern RTX features with a low-profile, bus-powered design, making it particularly suitable for compact PC upgrades where space and PSU connectivity are limited.
